Not every entrance is suited to a sliding door. Where the architecture calls for a traditional hinged door, where fire egress requirements demand a specific leaf configuration, or where a building’s accessible design standard must meet Singapore’s SS332:2018, the automatic swing door is the appropriate specification.
ACCESSCO’s automatic swing door solutions are engineered for intensive commercial and institutional use, combining high-torque performance with a compact operator and a specification list that addresses the most demanding project requirements, including a maximum door leaf weight of 350kg, a 110-degree opening angle, and a two-hour TUV fire resistance rating.
Built to handle frequent operation and heavier door leaves, delivering consistent opening force and controlled closing under demanding conditions.
Supports low-energy, reduced-speed, and push-and-go modes to ensure safe and comfortable use in environments with mobility-restricted users.
Compatible with various activation devices, safety sensors, electric locks, and building management systems, with easy parameter adjustment for different site conditions.
ACCESSCO Automatic Swing Doors are engineered for intensive daily use, combining high-torque performance with a compact operator design to support heavy, large door leaves.
Designed for reliability in demanding environments, the system delivers smooth, controlled motion while maintaining stable operation across commercial, healthcare, and public building entrances.
This system is often used in areas requiring controlled speeds and low-energy operation. It supports accessibility standards while ensuring safe interaction for all users.
Adjustable parameters for speed, force, and timing allow the door to be fine-tuned to site requirements, while certified durability and compliance ensure long-term reliability with minimal maintenance.
| Mains Connection | 230V AC 50/60Hz |
| Power Consumption | 85 W |
| Integrated Progamme Switch | Permanently Open ~ OFF ~ Auto |
| In The Event Of Power Failure | Door Closer Function |
| Drive Dimension | Height 85mm x Width 129mm x Length 684mm |
| Clear Opening Width | Single Leaf 700mm ~ 1400mm |
| Closing Force | EN3 ~ EN6 |
| Maximum Weight Per Leaf | 350kg |
| Hold Open Time | 0 - 60sec |
| Door Opening Angle | 110 Degree |
| Operating Temperature | -10°C to +55°C |
| Protection | IP40 |
| Durability | TUV Cyclic Endurance Test to 500,000 |
| Fire Resistance | TUV Fire Test to 2-Hour |
| Certificate of Conformity | SS332:2018 |
The weight of the door leaf is one of the most frequently underspecified parameters in automatic swing door projects. Heavy timber, steel-framed, or fire-rated door constructions can exceed the capacity of operators specified on standard assumptions.
ACCESSCO’s swing door operator supports a maximum weight per leaf of 350kg, which accommodates the full range of door leaf constructions encountered in commercial, healthcare, and institutional environments without requiring a specialist heavy-duty system.
The operator supports clear opening widths from 700mm to 1,400mm per leaf in single configuration, and up to 2,800mm in double-leaf, covering accessibility requirements including powered wheelchair circulation.
Automatic swing doors serve a wide range of users, including elderly individuals, wheelchair users, and those with limited upper body strength.
The operator supports low-energy, reduced-speed, and push-and-go modes, allowing safe and comfortable use across different user groups.
In mobility-restricted environments, these are functional requirements rather than convenience features.
ACCESSCO’s swing door operator is TÜV fire-tested to 2 hours, ensuring compatibility with fire-rated door assemblies and compliance with Singapore fire safety requirements.
Certified to SS332:2018, Singapore’s standard for automatic door operators, simplifying regulatory approval and documentation.
| Feature | Description |
|---|---|
350kg Maximum Door Leaf Weight |
The 350kg per leaf capacity covers virtually every commercial and institutional door construction, including heavy fire-rated assemblies, solid timber doors, and steel-framed configurations. This removes the need to specify a separate heavy-duty platform for demanding applications. |
110-Degree Opening Angle |
A 110-degree opening angle provides wide, unobstructed access for all users, including those with mobility aids. In healthcare and institutional environments where equipment, stretchers, and wheelchairs must pass through freely, this is a material operational consideration. |
TÜV Cyclic Endurance Tested (1,000,000 Cycles) |
Independent TUV testing to one million operating cycles provides a documented durability benchmark that facilities managers and procurement teams can rely on for long-term asset planning, rather than a manufacturer’s estimate. |
TÜV Fire-Resistance Tested (2 Hours) |
Two-hour fire-resistance testing confirms that the operator is compatible with fire-rated door assemblies on egress routes and at compartment boundaries, a prerequisite for specifying fire-rated openings in Singapore’s commercial and institutional building stock. |
SS332:2018 Certified |
SS332:2018 compliance is Singapore’s national standard for automatic door operators. Certification simplifies the regulatory approval process and provides the documentation required by building authorities, fire consultants, and main contractors. |
Accessible Operation Modes |
Low-energy, reduced-speed, and push-and-go modes allow the operator to be configured for different user groups and operational contexts within the same installation. This makes ACCESSCO’s automatic swing door solutions particularly well-suited to healthcare, aged care, and public-access environments where the breadth of the user population must be considered at the specification stage. |
Broad System Compatibility |
The operator is compatible with activation devices, safety sensors, electric locks, and building management systems. Speed, force, hold-open time, and closing force parameters are all adjustable across EN3 to EN6, allowing the system to be fine-tuned to the specific conditions at each site. |
BCA-Registered & BizSafe-Certified |
Every ACCESSCO installation is carried out in accordance with Singapore’s construction and workplace safety regulatory framework, providing the compliance assurance required for commercial and institutional project procurement. |
The combination of 350kg capacity, fire resistance, and SS332 compliance makes this ideal where sliding doors are unsuitable.
In healthcare environments, accessible modes and wide opening angles ensure usability across all users, with adjustable closing force (EN3–EN6) for varying site conditions.
Planning consideration: Surface-mounted design requires allowance for dimensions (H85mm × W129mm × L684mm).
| Sector | Application |
|---|---|
Healthcare & Medical Facilities |
An automatic door for hospital wards, clinical areas, and main entrances must meet fire rating, accessibility, and heavy door leaf requirements simultaneously |
Offices & Corporate Buildings |
Swing doors integrate with access control systems and the architectural language of the entrance |
Hospitality & Hotels |
Controlled closing and quiet operation contribute to the guest experience |
Government & Institutional Buildings |
SS332:2018 compliance and fire resistance certification are primary requirements |
Retail & Mixed-Use Developments |
Accessible operation modes serve a broad public user group |
Educational & Aged Care Facilities |
Reduced-speed and low-energy modes are specified as standard |
As a specialist automatic swing door manufacturer, supplier and BCA-registered contractor in Singapore, ACCESSCO works with architects, main contractors, facilities managers, and developers from early specification through to post-installation maintenance.
Whether your project involves a single accessible entrance or a multi-door programme across a large development, our team provides the technical guidance, compliance documentation, and installation expertise to deliver the right outcome.
Contact us to arrange a consultation, or download the product brochure for complete technical documentation.
The operator supports a maximum door leaf weight of 350kg, which covers the full range of commercial and institutional door constructions, including solid timber, steel-framed, and fire-rated assemblies.
For projects where the door leaf weight is close to or at this limit, we recommend confirming the exact leaf weight during the site assessment to ensure the operator is correctly specified and commissioned.
Yes. The operator accommodates clear opening widths of 700mm to 1,400mm per leaf in a single-leaf configuration and 1,400mm to 2,800mm in a double-leaf configuration. The 110-degree opening angle also ensures that the clear passage width at full open exceeds the minimum requirements for wheelchair access under Singapore’s accessibility guidelines.
Where a project has specific accessibility dimensions required by a consultant or authority, we advise confirming them during the specification stage to ensure the correct configuration is selected from the outset.
Yes, and this is one of the primary applications for which the system is designed.
The operator supports low-energy, reduced-speed, and push-and-go modes, which can be configured to open the door gently and hold it open for a defined period to accommodate slower-moving users.
The 110-degree opening angle and 350kg weight capacity mean that the system is equally applicable to heavy, wide doors in healthcare or aged care environments where both the door construction and the user population place greater demands on the operator than a standard commercial entrance.
In the event of a power failure, the operator defaults to the door closer function, meaning the door behaves as a standard manual door closer rather than a powered operator. This ensures that the door continues to close in a controlled manner and that the fire egress function of the door assembly is maintained without powered operation.
For environments where powered operation must be maintained during a power interruption, integration with an uninterruptible power supply should be discussed during the design stage.
Automatic swing doors are generally more energy efficient than sliding doors as the operator requires less sustained power during each cycle. The Push & Go functionality further supports this by activating the powered operator only when manual force is applied, making it suitable for environments where powered assistance is needed on demand rather than continuously.
